New Arrivals

BARGAIN Bundle Pack E4C Detailed Overhead Line Equipment Platform Mast Structures Kit - Parts to construct Four x SERIES 2 - Two Track Platform Cantilever type 130mm Arm Masts, including Magnetic Bases, Magnetic Registration Arms and Return Conductor Wire Mounts. OO Gauge SET E4-22 - product code 4WH0900422 PLEASE READ THE FULL PRODUCT DESCRIPTION BELOW This Bundle Set E4-22 includes:- 4 x E4-3 - Series 2 Two Track Platform 130mm Cantilever Structure Kits 2 x E4-6 - Left Hand Magnetic Registration Arms Sets 2 x E4-7 - Right Hand Magnetic Registration Arms Sets 1 x E4-10 - Conductor Wire Mounts (Pack of 5) All parts are supplied unpainted on sprues. Preparation and assembly with glue is required. Before painting it is recommended to apply a light coat of primer. Instructions are available on-line or paper copy by special request only at the time of ordering. Glue and paint is not included. OHLE Structure kit (SET E4-22) each Mast assembled dimensions:- Maximum height above your platform (including base) - 101mm Overall length of structure (across the tracks) - 131mm Max width of structure/base - 14mm Nominal height of contact wire with Mast fitted onto an 18mm high platform (if wire fitted to Magnetic Registration Arms) - 78mm above baseboard [wires not included] Please see the downloadable "OHLE Equipment Product Guide" in the Attachments TAB above.

Read more less

BARGAIN Bundle Pack E4A Detailed Overhead Line Equipment Mast Structures Kit - Parts to construct Four x SERIES 2 - Two Track Cantilever type 100mm Arm Masts, including Magnetic Bases, Magnetic Registration Arms, Wire Tensioners and Return Conductor Wire Mounts. OO Gauge SET E4-20 - product code 4WH0900420 PLEASE READ THE FULL PRODUCT DESCRIPTION BELOW This Bundle Set E4-20 includes:- 4 x E4-1 - Series 2 Two Track Cantilever Structure Kits 2 x E4-6 - Left Hand Magnetic Registration Arms Sets 2 x E4-7 - Right Hand Magnetic Registration Arms Sets 1 x E4-8 - Post Mounted Tensioners (Pack of 2) 1 x E4-10 - Conductor Wire Mounts (Pack of 5) All parts are supplied unpainted on sprues. Preparation and assembly with glue is required. Before painting it is recommended to apply a light coat of primer. Instructions are available on-line or paper copy by special request only at the time of ordering. Glue and paint is not included. OHLE Structure kit (SET E4-20) each Mast assembled dimensions:- Maximum height above baseboard (including base) - 115mm Overall length of structure (across the tracks) - 103mm Max width of structure/base - 14mm Nominal height of contact wire (if fitted to Magnetic Registration Arms) - 78mm above baseboard [wires not included] Please see the downloadable "OHLE Equipment Product Guide" in the Attachments TAB above.

Read more less

BARGAIN Bundle Pack E4B Detailed Overhead Line Equipment Mast Structures Kit - Parts to construct Four x SERIES 2 - Two Track Cantilever type 130mm Arm Masts, including Magnetic Bases, Magnetic Registration Arms, Wire Tensioners and Return Conductor Wire Mounts. OO Gauge SET E4-21 - product code 4WH0900421 PLEASE READ THE FULL PRODUCT DESCRIPTION BELOW This Bundle Set E4-21 includes:- 4 x E4-2 - Series 2 Two Track 130mm Cantilever Structure Kits 2 x E4-6 - Left Hand Magnetic Registration Arms Sets 2 x E4-7 - Right Hand Magnetic Registration Arms Sets 1 x E4-8 - Post Mounted Tensioners (Pack of 2) 1 x E4-10 - Conductor Wire Mounts (Pack of 5) All parts are supplied unpainted on sprues. Preparation and assembly with glue is required. Before painting it is recommended to apply a light coat of primer. Instructions are available on-line or paper copy by special request only at the time of ordering. Glue and paint is not included. OHLE Structure kit (SET E4-21) each Mast assembled dimensions:- Maximum height above baseboard (including base) - 115mm Overall length of structure (across the tracks) - 131mm Max width of structure/base - 14mm Nominal height of contact wire (if fitted to Magnetic Registration Arms) - 78mm above baseboard [wires not included] Please see the downloadable "OHLE Equipment Product Guide" in the Attachments TAB above.

Read more less

Detailed N-Gauge Overhead Line Equipment Mast Kit - Mk1 Type B Single Cantilever Kit with Lattice Mast 67mm Span, including Magnetic Base Typical of the style fitted on the West Coast Main Line.SET E11-14 - product code 2WH0901114PLEASE READ THE FULL PRODUCT DESCRIPTION BELOWDetailed N-Gauge Overhead Line Equipment Cantilever Mast Kit - Mk1 Type B Single Cantilever Kit with Lattice Mast 67mm Span, including Magnetic Base Typical of the style fitted on the West Coast Main Line. PLEASE READ THE FULL PRODUCT DESCRIPTION BELOWN Gauge SET E11-14 - product code 2WH0901114This set E11-14 includes parts to construct one (1) Mk1 Type A Single Cantilever Structure for up to 2 Tracks (1 Lattice Masts, 1 Base and 1 Span section).  The two Pile Driven style Bases included in the kit come with magnets to fit into the bases and OHLE structure. The use of magnets allows the OHLE structures to be easily removed and re-fitted on your layout.PLEASE NOTE - the registration arms are NOT included and should be purchased separately.N-Gauge Registration Arm options for the Mk1 Style OHLE are available to Purchase Separately as follows:- SET E11-5 - Mk1 Registration Arms and Catenary Wire Supports for Type A & B Structures (SET E11-5) - product code 2WH0901105 All parts are supplied unpainted; before painting it is recommended to apply a light coat of primer.Regarding the spacing of OHLE masts, the real railway mast spacing can be vary between about 20metres and 70metres which equates to 130 to 470mm in N Gauge. In general mast spacing is likely to be closer together at junctions and on sharper curves.OHLE Structure kit (SET E11-14) dimensions:- Maximum height above baseboard (including base) - 65mm Overall length of structure (across the tracks) - 74mm Max width of structure/base - 8mm Please see the downloadable "OHLE Equipment Product Guide" in the Attachments TAB above.

Read more less
